Professional Meat Processing Machinery Manufacturer Providing Customized and Reliable Solutions for Global Food Industry
1 Years
| Ask Lasest Price | |
| Brand Name : | EPS |
| Model Number : | 005 |
| Certification : | CE ISO |
| Price : | $3000-6000 |
| Payment Terms : | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability : | 2000 sets |
| Delivery Time : | 5-15 days |
The Sausage Linking and Twisting Machine is a high-performance solution designed for precise and automatic sausage portioning and linking. It ensures uniform sausage lengths and tight, reliable twists, making it ideal for high-volume commercial sausage production. It can be integrated with vacuum fillers or used as part of a full sausage production line.
Technical Parameters:
| 1 | Total power | 14KW |
| 2 | Power supply | AC380V+N+PE |
| 3 | Direct filling capacity | 4000kg~6500kg/h (depending on the product) |
| 4 | Quantitative accuracy of direct filling | ±1.5g/100g (minced meat),±2g/100g (meat, depending on the size of the meat) |
| 5 | Fixed length accuracy | protein casing ± 1mm, natural casing ± 3mm (raw product) |
| 6 | Hopper volume | 250L, and the hoist max lifting weight is 250kg |
| 7 | Vacuum pressure | 0~-0.1mpa |
| 8 | Maximum twisting speed | 1500 knots/min |
| 9 | Twisting length range | 30~380mm |
| 10 | Twisting sausage diameter | φ16~φ38 |
| 11 | Hanging length of hanging machine | 600mm |
| 12 | Dimensions of the production line (LxWxH) | 7090*1362*2255mm |
| 13 | Weight | ≈2020kg |
Product Features:
Automatic Linking & Twisting
Links and twists sausages into exact lengths automatically,
significantly improving productivity and product consistency.
High Precision Servo Control
Equipped with servo motors or pneumatic drive for exact twist
spacing and weight control.
Adjustable Portion Size & Twist Length
Easily set sausage length (e.g., 80mm–300mm) and portion weight via
touchscreen PLC.
Suitable for All Casings
Works with natural, collagen, or cellulose casings in multiple
diameters.
Continuous Operation
Can be synchronized with sausage filler for uninterrupted
production.
Hygienic Stainless Steel Design
Made of SUS304 stainless steel, fully washdown-compatible and CE certified.
Application:
Pork and beef sausages
Chicken sausages
Hot dogs / frankfurters
Cheese or vegetable-filled sausages
Plant-based or vegan sausages
Spiced, smoked or flavored links
Packing and Shipping:
Our food processing machines are carefully packed with protective film, foam, and export-grade wooden cases to ensure safe delivery. We offer flexible shipping options by sea, air, or expressbased on your needs. With rich experience in international logistics, we ensure fast and reliable delivery worldwide.
Q1: How long is your delivery time?
A1: Generally, it will take 15 to 30 days after receiving your
advance payment. The specific delivery time depends on the items
and the quantity of your order.
Q2: What's your terms of payment?
A2: By Wire Transfer (T/T) and other methods. Please contact our
customer service for specific details.
Q3: Where is the market for the product and what is the market
advantage?
Our market covers almost the whole of Europe, America, Asia, and
Africa, and exports to more than 50 countries.
Q4: How does your factory do in terms of quality control?
A4. Quality is the priority. We always attach great importance to
quality control from the very beginning to the end of the
production. Every product will be fully assembled and carefully
tested before it's packed for shipment.
|
|
